Description Temperature Transmitter 2088
The temperature transmitter is composed of a temperature sensor and a signal converter. The signal converter is installed in the cold terminal junction box of the temperature sensor. The temperature sensor is affected by temperature to produce resistance or potential effect, and a differential voltage signal is generated after conversion. This signal is amplified by the amplifier, and then converted by voltage and current, and outputs a current signal of 4-20mA or other signals of 0-5V/0-10V corresponding to the range.
The temperature transmitter organically integrates the temperature sensing element (thermal resistance or thermocouple) with the signal conversion and amplification unit, and is used to measure liquid, steam and other gaseous media in the range of -200-1600 °C in various processes. The temperature of the solid surface. It is usually used in conjunction with display instruments, recording instruments and various control systems. It has the characteristics of simple structure, convenient installation, use and maintenance, and has been widely used in petroleum, chemical, metallurgy, power stations, light industry and other departments.
Temperature transmitters are divided into three categories: ordinary type, explosion-proof type and digital display integration. Among them, ordinary type and flameproof type can choose different built-in temperature transmitter modules to meet different application requirements of users. According to different temperature sensors, temperature transmitters are divided into two series: thermocouples and thermal resistances
Detailed Images Temperature Transmitter 2088
Specification Temperature Transmitter 2088
| Measurement Range | -200~1800℃ |
| Conventional accuracy | ±0.25% |
| Supply voltage | 13~30V, DC |
| Load resistance | 0~850Ω |
| Output signal | 4~20mA |
| Basic error | ±0.2%, ±0.5% |
| Display mode | LCD display |
| Ambient temperature influence | 0.25%/10℃ |
| Cold junction compensation error | 0.5%/10℃ |
| Explosion-proof mark | dⅡBT4 |
| Protection class | IP65 |
| Input type | RTD, Pt100, 2-wire or 3-wire thermocouple (all known types) |
| Ambient temperature | -40-85℃, with display type -10-70℃ |
| Ambient humidity | 0-95%RH, non-condensing |
| Display options | pointer meter or digital LCD display optional |
| Protection tube material | 1Cr18Ni9Ti or ceramic or corundum tube |
Feature Temperature Transmitter 2088
1.Two-wire transmission is possible. The two wires that power the signal converter also carry the output signal
2.Output constant current signal or constant voltage signal, with strong anti-interference ability and good remote transmission performance.
3.The signal converter is encapsulated into a module with epoxy resin, which has the advantages of anti-vibration, corrosion resistance and moisture resistance, and can be used in places with poor conditions.
4.The resistance signal or millivolt signal of thermal resistance/thermocouple is directly converted into 4-20mA current output by the signal converter, and the signal is transmitted by ordinary cable, which can save the expensive compensation wire.
5.The temperature transmitter with on-site display can not only output a current signal of 4-20mA, but also read the measured temperature at the temperature measurement site, which brings great convenience to the operator.
6.High precision, anti-interference, good long-term stability, maintenance-free, and remote transmission (up to 1000 meters).
Applications Temperature Transmitter 2088
Compatible with 316LSS,noncorrosive gases & liquids.
Special use in harsh environment conditions
